Description
Medium-contour (.75″ at the muzzle) barrel features a Ruger Precision® Rifle Hybrid Muzzle Brake to effectively reduce recoil while minimizing noise and blast to the sides of the shooter.
Patented multi-magazine interface functions interchangeably with AICS and M110/SR-25/DPMS/Magpul-style magazines (works with some M14 magazines).
Ruger Marksman Adjustable trigger is externally adjustable, with a trigger pull range of 2.25 to 5 pounds; wrench is stored in the bolt shroud.
In-line recoil path manages recoil directly from the rear of the receiver to the buttstock, not through a traditional bedding system, providing maximum accuracy potential.
Ruger Precision® MSR stock with QD sling attachment points features a bottom Picatinny rail and soft rubber buttpad. The left-folding stock hinge is attached to an AR-style buffer tube and accepts any AR-style stock. Length of pull and comb height are adjustable.
Cold hammer-forged, chrome-moly steel barrel with 5R Rifling at minimum bore and groove dimensions, minimum headspace and centralized chamber.
15″ aluminum free-float handguard is hard-coat anodized aluminum and features Magpul® M-LOK® slots on all four sides for improved scope clearance for long-range scopes and easy mounting of M-LOK-compatible rails and accessories.
Ambidextrous manual safety for left- or right-handed lever manipulation.
20 MOA Picatinny rail secured with # 8-40 screws for increased long-range elevation capabilities.
“Upper” receiver and one-piece bolt are precision CNC-machined from pre-hardened 4140 chrome-moly steel to minimize distortion.
Three-lug bolt with 70° throw features dual cocking cams and a smooth-running, full diameter bolt body. Bolt body is nitrided for corrosion resistance, smooth operation and durability.
Barrel can be replaced easily by a competent gunsmith using headspace gauges.
Magazine well front is contoured for a positive grip when bracing against shooting supports.
Oversized bolt handle for positive bolt manipulation, with a 5/16″-24 thread pattern for easy replacement. Bolt disassembly tool is stored in the Ruger Precision® Rifle Billet Aluminum Bolt Shroud for easy striker channel cleaning.
“Lower” magazine well halves are precision machined from aerospace-grade 7075-T6 aluminum and are Type III hard-coat anodized for maximum durability.
Extended trigger-reach AR-style grip and 45° ambidextrous safety selector. May be configured with any AR-style grip and selector.
Also includes: two, 10-round Magpul® PMAG® magazines.
StockFolding, Adjustable Length of Pull and Comb Height
FinishType III Black Hard-Coat Anodized – Desolve® Bare Reduced Camo
Barrel Length24″
BarrelCold Hammer-Forged, 5R Rifling
Thread Pattern5/8″-24
Twist1:8″ RH
Grooves5
Weight10.7 lb.
Capacity10
Height7.30″
Overall Length43.25″-46.75″
Length of Pull12″ – 15.50″
Folded Length35.60″
Width3.30″
UPC7-36676-18025-7
